QuikDeck®
QuikDeck is a high-performance suspended access system that can be erected quickly and assembled to almost any shape and size.
Videos & photos
Exciting & unique: QuikDeck suspended access platform
By activating the video you accept the YouTube privacy policy.
To the privacy policy
Attention: You have deactivated JavaScript in your browser and can therefore not see all contents.
Bridge construction with QuikDeck
By activating the video you accept the YouTube privacy policy.
To the privacy policy
Attention: You have deactivated JavaScript in your browser and can therefore not see all contents.
Bridge refurbishment with QuikDeck
2
Product advantages
Work productively
- Fast delivery to the site thanks to a capacity of 460 m2 per low-loader truck
- Work in parallel is possible with up to seven work platforms on top of each other that are accessible for machines
- Equipment can be leapfrogged and relocated as work progresses.
- High assembly speed due to small number of components
- Load capacity up to 300 kg/m2 (load class 4) depending on configuration
- Suitable for new construction, renovation and repair
- Installation in the air or on the ground
- Constructions in almost any size and shape possible thanks to modular design
Work safely
- Clear and trip-free working environment thanks to clean, smooth surfaces
- Protection from falling equipment, debris or tools due to robust construction
- Very safe thanks to high load capacity of the suspension chains
- Easy and fast assembly without special tools or knowledge
- Key components are equipped with handles
- Components are dismountable and fit through narrow openings
Application & use
Download the user guide here. Click on the name of a chapter to access it directly.
Overview of user guide
Technical data
Beam lengths | 42 | 83 | 123 | 125 | 128 | 168 | 177 | 208 | 250 cm |
Beam connections | Knots |
Planks | 122 x 244 x 1.9 cm |
Length of suspension chains | 180 | 360 | 550 | 730 | 1230 cm |
Corrosion protection | Load-bearing components are hot-dip galvanised |
Load capacity | Up to 300 kg/m2 (load class 4) |
